Chicago Dryer Air Cylinder, 1-1/2" Bore × 3-1/2" Stroke – 0208-060

The 0208-060 Air Cylinder is a pneumatic linear actuator used in Chicago Dryer flatwork ironer and folder assemblies where moderate-force, mid-range stroke motion is required. The 1-1/2″ bore provides increased output force compared to smaller bore cylinders, and the 3-1/2″ stroke supports controlled extension for positioning, clamping, or transfer mechanisms.

This air cylinder is installed within internal pneumatic circuits and actuates mechanical components through regulated compressed air. Bore size, stroke length, port configuration, and mounting style must match the existing assembly to maintain proper force output and motion timing.

Maintenance Tip: Verify supply air pressure and check for rod alignment during installation to prevent side-load seal failure.

CICUS supplies field-matched pneumatic motion components engineered for commercial flatwork ironer systems.
