1003-967 – Chicago Dryer Tev-Tex Ribbon, 3-1/2″ x 187-1/2″ with Pin

The 1003-967 Tev-Tex Ribbon is a high-temperature carrier ribbon used in Chicago Dryer flatwork ironer systems to support and guide padded ironer belts through the feed and return path. The Tev-Tex synthetic construction provides dimensional stability and resistance to continuous heat exposure within chest-type ironers.

This ribbon measures 3-1/2″ wide by 187-1/2″ long and includes a factory-installed pin for secure mechanical connection within the ribbon drive assembly. Correct ribbon length and pin engagement are critical for maintaining belt tracking accuracy, balanced tension, and consistent ironer output.

Maintenance Tip: Measure installed ribbon length during scheduled service to detect stretch before it affects belt alignment.

CICUS engineers and supplies ironer textile systems built for durability and precise fit in commercial laundry operations.

==============================

⚙️ Technical Specifications

Spec Detail

Brand Chicago Dryer
SKU 1003-967
Product Type Tev-Tex Ribbon
Material Tev-Tex Synthetic
Width 3-1/2″
Length 187-1/2″
Attachment Pre-installed Pin
Application Belt Support and Tracking
Machine Type Flatwork Ironer
Compatibility Chicago Dryer ironer systems
